CPP Film Granulation Equipment

CPP Film Granulation Equipment Description:

The CPP film granulation equipment is specially designed for blown film, garment packaging bag, industrial waste film, washed agricultural film, garbage film, non-woven bag, ton bag granulation. The production line of CPP film pelletizer includes belt conveyor, cutting compactor, extruder, pelletizing unit, pellet cooling, drying unit and storage tank. It combines cutting, extrusion and granulation together. The compaction compactor generates frictional heat during the compaction process, which helps to dry and remove water from the cleaned film.

CPP Film Granulation Equipment-fangsheng

CPP Film Granulation Equipment Features:

1. The whole CPP film granulation line is continuously improved on the basis of advanced technology at home and abroad, with reasonable design and beautiful appearance, and the parts in contact with materials are made of stainless steel;
2. The CPP film granulation line is directly cut by water ring above the die, either horizontal or vertical water ring. After cooling, the water enters the centrifugal dehydrator, and then is sent to the storage bin by the fan, so there will be no problem of wire breakage;
3. The CPP film granulation line is non-stop hydraulic screen changing device, and there is a pressure sensor on the die head to prompt the screen to be changed. The screen change does not need to be stopped. The screen change speed is fast and convenient.
4. The split automatic power distribution system is adopted to ensure the safe and normal operation of the motor;
5. The process is simple, the operation is convenient, the technology is advanced, and it is suitable for granulating a variety of different waste plastics.

CPP Film Granulation Equipment Application:

CPP Film Granulation Equipment-fangsheng

CPP Film Granulation Equipment Video:

CPP Film Granulation Equipment Technical Parameter:



FS series single-stage granulator machine
Model Extruder Screw diameter(mm) L/D ratio Power(kw) Productivity(PE)(kg/h) Productivity(PP)(kg/h)
FSJ70 70/33 φ70 33:1 110 110-150 100-130
FSJ85 85/33 φ85 33:1 150 180-250 150-200
FSJ100 100/33 φ100 33:1 210 280-350 250-300
FSJ130 130/33 φ130 33:1 300 480-550 400-480
FSJ160 160/33 φ160 33:1 370 650-750 550-650
FSJ180 180/33 φ180 33:1 460 800-1000 750-850
FS series double-stage granulator machine
Model FSJ100/120 FSJ130/130 FSJ160/160 FSJ180/200
First extruder parameter
Screw diameter(mm) φ100 φ130 φ160 φ180
L/D ratio 33 33 30 30
Extruder motor(kw) 90 132 185 250
Heating power(kw) 45 55 70 70
Screw speed(RPM) 0-120 0-120 0-120 0-120
Second extruder parameter
Screw diameter(mm) φ120 φ130 φ160 φ200
L/D ratio 10-15 10-15 10-15 10-15
Extruder motor(kw) 30 45 55 75
Heating power(kw) 30 35 45 60
Screw speed(RPM) 0-120 0-120 0-120 0-120
Productivity(kg/h) 250-350 400-550 500-700 800-1000

CPP Film Granulation Machine Detail:

CPP Film Granulation Equipment-fangsheng
Detail 1
CPP Film Granulation Equipment-fangsheng
Detail 2
CPP Film Granulation Equipment-fangsheng
Detail 3
CPP Film Granulation Equipment-fangsheng
Detail 4
CPP Film Granulation Equipment-fangsheng
Detail 5
CPP Film Granulation Equipment-fangsheng
Detail 6
