HDPE Bottle Recycling Machine

HDPE Bottle Recycling Machine Instruction:

HDPE bottle recycling machine is suitable for washing crushing drying different kinds of plastic bottles such as HDPE bottle, PET bottle PP bottle etc, HDPE recycling machine is the ideal equipment to recycle all kinds of plastic bottles.
1. We provide different capacity for our customer:200kg/h, 300kg/h, 500kg/h and 1000kg/h.
2. According to your material,you may choose different device.
3. According to your country condition,you may choose full automatic line or semi-automatic line.
4. Our customer may purchase device based on his own condition.
5. We providing turn-key project for our customer.
6. Design-produce the machine-installment-testing.
7. Based on your workshop condition,our design always matched to your workshop mostly.
HDPE Bottle Recycling Machine-fangsheng

HDPE Bottle Recycling Machine Function:

This HDPE bottle recycling line is used for milk bottle irrigation recycling .
So we design the HDPE recycling line for the HDPE milk bottles with following function:
1. Wet crushing: crushing the HDPE bottles into flakes at the same time,we spray the water for washing.
2. Friction washing: removing mostly sand/earth by high speed paddles.
3. Sink float tank: separating the sinking materials from HDPE flakes if containing.
4. Dewatering: dewatering the washed HDPE flakes and clean the materials for further step.

HDPE Recycling Machine Video:

HDPE Recycling Machine Detail:

HDPE Bottle Recycling Machine-fangsheng
High-speed Friction Washer
HDPE Bottle Recycling Machine-fangsheng
Crusher Machine
HDPE Bottle Recycling Machine-fangsheng
Dewatering Machine
HDPE Bottle Recycling Machine-fangsheng
Steam washer
HDPE Bottle Recycling Machine-fangsheng
Label scfraping machine
HDPE Bottle Recycling Machine-fangsheng
Label separator by air

HDPE Recycling Machine Technical Parameter:

Name Motor power (kw) Dimension (mm) Water consumption (T/H) Stainless steel standard (mm) Electric standard
Belt conveyor 2.2 3500*900*3000 According to customers standard
Label scraping machine 11 2600*1200*1800 0.6-1.0 3-5
Manual separating machine 2.2 6000*800*1200
Metal detectory 0.4 2200*1200*1500 3-5
Belt conveyer 2.2 3500*900*3000
Crusher 37 2200*2200*3000 0.6-1.0
Screw converor 3 2800*800*2600 3-5
High speed friction washer 30 3200*1400*2000 1-2 3-5
Screw conveyer 3 2800*800*2600 3-5
Floating washer 3*2 5200*1700*2200 0.5-1.5 3-5
Screw conveyer 36 2800*800*2600 3-5
Steam washer 7.5 1800*1800*2700 0.5-1.5 3-5
Screw conveyer 3 2800*800*2600 3-5
Floating washer 3*2 5200*1700*2200 0.5-1.5 3-5
Screw conveyer 3 2800*800*2600 3-5
Dewatering machine 5.5 800*2200*2200 5
Drying system 11 3500*2200*2200 3-5
Label separater 4 800*1100*3800
Storage hopper 1500*1500*3800
Electric elements 2000*450*1780
