PE Film Granulator Equipment

PE Film Granulator Equipment Description:

This kind of PE film granulator equipment is very suitable for the recycling of various waste plastics, such as plastic films, sheets and pattern materials. Adopt PID temperature control, non-stop filter screen hydraulic reversal, high degree of automation. The special feature of this PE film granulator equipment is the particles with good plastic properties.

PE Film Granulator Equipment-fangsheng



PE Film Granulator Equipment Features:

1.The PE film granulator system has the versatility of crushing and granulating, the whole plastic bag can be directly granulated without crushing.
2. The PE film granulator machine  has a double-column online screening exchanger with a larger filtration area.
3. Water ring particle cutting to avoid material contamination.

PE Film Granulator Machine Application:

PE Film Granulator Equipment-fangsheng



PE Film Granulator Machine Video:



PE Film Granulator Machine Technical Parameter:

FS series single-stage granulator machine
Model Extruder Screw diameter(mm) L/D ratio Power(kw) Productivity(PE)(kg/h) Productivity(PP)(kg/h)
FSJ70 70/33 φ70 33:1 110 110-150 100-130
FSJ85 85/33 φ85 33:1 150 180-250 150-200
FSJ100 100/33 φ100 33:1 210 280-350 250-300
FSJ130 130/33 φ130 33:1 300 480-550 400-480
FSJ160 160/33 φ160 33:1 370 650-750 550-650
FSJ180 180/33 φ180 33:1 460 800-1000 750-850
FS series double-stage granulator machine
Model FSJ100/120 FSJ130/130 FSJ160/160 FSJ180/200
First extruder parameter
Screw diameter(mm) φ100 φ130 φ160 φ180
L/D ratio 33 33 30 30
Extruder motor(kw) 90 132 185 250
Heating power(kw) 45 55 70 70
Screw speed(RPM) 0-120 0-120 0-120 0-120
Second extruder parameter
Screw diameter(mm) φ120 φ130 φ160 φ200
L/D ratio 10-15 10-15 10-15 10-15
Extruder motor(kw) 30 45 55 75
Heating power(kw) 30 35 45 60
Screw speed(RPM) 0-120 0-120 0-120 0-120
Productivity(kg/h) 250-350 400-550 500-700 800-1000

PE Film Granulator Machine Detail:

PE Film Granulator Equipment-fangsheng
Detail 1
PE Film Granulator Equipment-fangsheng
Detail 2
PE Film Granulator Equipment-fangsheng
Detail 3
PE Film Granulator Equipment-fangsheng
Detail 4
PE Film Granulator Equipment-fangsheng
Detail 5
PE Film Granulator Equipment-fangsheng
Detail 6
