PET Bottle Crushing Washing Line

PET Bottle Crushing Washing Line Description:

PET bottle crushing washing line is used in the field of PET waste bottle or sheet recycling. PET bottle washing line through the process of de-marking, sorting, crushing, washing and drying, and the waste bottles will become bottle flakes. The cleaned bottle flakes are widely used in the plastics and chemical fiber industries, such as sheet and profile production, and chemical fiber production.

PET Bottle Crushing Washing Line-fangsheng

PET Bottle Washing Line Features:

1. The cleaned bottle flakes can be used to produce polyester staple fiber, packing tape, PET plastic pellets, PET transparent film and sheets, etc. The top bottle flakes can be used for blowing bottles.

2. PET bottle washing line can be designed according to the degree of dirty bottle body, and to ensure that the quality of the final product is very clean.

3. The output of PET bottle washing line produced by Fangsheng Machinery can be selected from 500 kg/h to 6000 kg/h.

PET Bottle Washing Line Application:

PET Bottle Crushing Washing Line-fangsheng

PET Bottle Washing Line Video:

Learn more about YouTube’s PET bottle washing line

PET Bottle Washing Line Detail:

PET Bottle Crushing Washing Line-fangsheng
High-speed Friction Washer
PET Bottle Crushing Washing Line-fangsheng
Crusher Machine
PET Bottle Crushing Washing Line-fangsheng
Dewatering Machine
PET Bottle Crushing Washing Line-fangsheng
Steam washer
PET Bottle Crushing Washing Line-fangsheng
Label scfraping machine
PET Bottle Crushing Washing Line-fangsheng
Label separator by air

PET Bottle Washing Line Technical Parameter:

Name Motor power (kw) Dimension (mm) Water consumption (T/H) Stainless steel standard (mm) Electric standard
Belt conveyor 2.2 3500*900*3000 According to customers standard
Label scraping machine 11 2600*1200*1800 0.6-1.0 3-5
Manual separating machine 2.2 6000*800*1200
Metal detectory 0.4 2200*1200*1500 3-5
Belt conveyer 2.2 3500*900*3000
Crusher 37 2200*2200*3000 0.6-1.0
Screw converor 3 2800*800*2600 3-5
High speed friction washer 30 3200*1400*2000 1-2 3-5
Screw conveyer 3 2800*800*2600 3-5
Floating washer 3*2 5200*1700*2200 0.5-1.5 3-5
Screw conveyer 36 2800*800*2600 3-5
Steam washer 7.5 1800*1800*2700 0.5-1.5 3-5
Screw conveyer 3 2800*800*2600 3-5
Floating washer 3*2 5200*1700*2200 0.5-1.5 3-5
Screw conveyer 3 2800*800*2600 3-5
Dewatering machine 5.5 800*2200*2200 5
Drying system 11 3500*2200*2200 3-5
Label separater 4 800*1100*3800
Storage hopper 1500*1500*3800
Electric elements 2000*450*1780
