Water Bottle Recycling Machine

Water Bottle Recycling Machine Instruction:

Water bottle recycling machine is widely used to recycle used water bottles and clean them into flakes. After cleaning, they can be made into granules by the next process, which is called granulation line. Plastic recycling machine is highly automatic operation and saves labor cost.
Water Bottle Recycling Machine-fangsheng

Water Bottle Recycling Machine Features:

1. Water bottle recycling machine can save labor. We provide bale opening and feeding system to feed bales evenly.
2. You can use manual sorting system to select different colors of bottles and non-PET materials.
3. 3. You can choose to use metal detector to remove any kind of metal from PET bottles.
4. Specially designed PET bottle pelletizer can easily get high output. Using water for wet grinding can reduce the wear of the blades.
Reduce the wear of the blades.
5. High speed dewatering machine and drying system will ensure the moisture of the final PET flakes <1%.
6. Fin de-dusting machine will remove the final label from the flakes and ensure the PVC content.

Bottle Recycling Machine Video:

Bottle Recycling Machine Detail:

Water Bottle Recycling Machine-fangsheng
High-speed Friction Washer
Water Bottle Recycling Machine-fangsheng
Crusher Machine
Water Bottle Recycling Machine-fangsheng
Dewatering Machine
Water Bottle Recycling Machine-fangsheng
Steam washer
Water Bottle Recycling Machine-fangsheng
Label scfraping machine
Water Bottle Recycling Machine-fangsheng
Label separator by air

Bottle Recycling Machine Technical Parameter:

Name Motor power (kw) Dimension (mm) Water consumption (T/H) Stainless steel standard (mm) Electric standard
Belt conveyor 2.2 3500*900*3000 According to customers standard
Label scraping machine 11 2600*1200*1800 0.6-1.0 3-5
Manual separating machine 2.2 6000*800*1200
Metal detectory 0.4 2200*1200*1500 3-5
Belt conveyer 2.2 3500*900*3000
Crusher 37 2200*2200*3000 0.6-1.0
Screw converor 3 2800*800*2600 3-5
High speed friction washer 30 3200*1400*2000 1-2 3-5
Screw conveyer 3 2800*800*2600 3-5
Floating washer 3*2 5200*1700*2200 0.5-1.5 3-5
Screw conveyer 36 2800*800*2600 3-5
Steam washer 7.5 1800*1800*2700 0.5-1.5 3-5
Screw conveyer 3 2800*800*2600 3-5
Floating washer 3*2 5200*1700*2200 0.5-1.5 3-5
Screw conveyer 3 2800*800*2600 3-5
Dewatering machine 5.5 800*2200*2200 5
Drying system 11 3500*2200*2200 3-5
Label separater 4 800*1100*3800
Storage hopper 1500*1500*3800
Electric elements 2000*450*1780
