PET Bottle Recycling Line

PET Bottle Recycling Line Instruction:

PET bottle recycling line is suit for PP/PE/PET Flakes, from crushing ,washing and drying in 300-500kgs/h , you can select the equip as your requirement , there have cold wash and hot wash for your choose, PET recycling line is a economic and more used to make good good quality pellets after wash .Each machine will be designed be perfect.
PET Bottle Recycling Line-fangsheng

1.Description

1. PET recycling line washing and drying line is suitable for high capacity.
2. PET recycling line washing is a whole line consists bottle label peeler, crusher,washing machine and dewatering machine.
3. PET recycling line washing is an automatic production line which produces high quality production.

2.Characteristic

1.Automatically works,conveying material,peeling label,crushing,washing,drying.
2.Hot washing for PET flakes by using steam.
3.Moisture for the end production.
4.Impurity pvc is less than 1% in production.

PET Recycling  Line Video:

PET Bottle Recycling Line Detail:

PET Bottle Recycling Line-fangsheng
High-speed Friction Washer
PET Bottle Recycling Line-fangsheng
Crusher Machine
PET Bottle Recycling Line-fangsheng
Dewatering Machine
PET Bottle Recycling Line-fangsheng
Steam washer
PET Bottle Recycling Line-fangsheng
Label scfraping machine
PET Bottle Recycling Line-fangsheng
Label separator by air

PET Recycling Line Technical Parameter:

Name Motor power (kw) Dimension (mm) Water consumption (T/H) Stainless steel standard (mm) Electric standard
Belt conveyor 2.2 3500*900*3000 According to customers standard
Label scraping machine 11 2600*1200*1800 0.6-1.0 3-5
Manual separating machine 2.2 6000*800*1200
Metal detectory 0.4 2200*1200*1500 3-5
Belt conveyer 2.2 3500*900*3000
Crusher 37 2200*2200*3000 0.6-1.0
Screw converor 3 2800*800*2600 3-5
High speed friction washer 30 3200*1400*2000 1-2 3-5
Screw conveyer 3 2800*800*2600 3-5
Floating washer 3*2 5200*1700*2200 0.5-1.5 3-5
Screw conveyer 36 2800*800*2600 3-5
Steam washer 7.5 1800*1800*2700 0.5-1.5 3-5
Screw conveyer 3 2800*800*2600 3-5
Floating washer 3*2 5200*1700*2200 0.5-1.5 3-5
Screw conveyer 3 2800*800*2600 3-5
Dewatering machine 5.5 800*2200*2200 5
Drying system 11 3500*2200*2200 3-5
Label separater 4 800*1100*3800
Storage hopper 1500*1500*3800
Electric elements 2000*450*1780
