Plastic Film Recycling Washing Machine

Plastic Film Recycling Washing Machine Introduction:

Plastic film recycling washing machine is dedicated to the crushing, cleaning and drying of PE PP films and PP woven bags. Plastic film recycling machine can be used to obtain clean crushing and drying from waste films. Plastic film recycling machine can work automatically and can be easily operated by only 3 to 4 people. Plastic film recycling washing line has the characteristics of high capacity, low energy consumption, and effective design. Plastic film recycling washing equipment produced by Fangsheng Machinery is made of stainless steel SUS304 to ensure reliable performance.

Plastic Film Recycling Washing Machine-fangsheng

Plastic Film Washing Machine Working Principle:

Plastic film recycling washing line is composed of conveyors, crushers (grinding machines), high-speed friction washers, floating washers, dehydrators, control cabinets and other components. First waste plastic (sorting), crushing (tearing), then rubbing cleaning, rinsing, and finally drying.

Plastic Film Recycling Machine Work Process:

Belt conveyor → crusher → high-speed friction machine → rinsing machine → screw feeder → dehydrator → screw feeder → rinsing machine → screw feeder → plastic squeezing machine

Plastic Film Washing Machine Application:

Plastic Film Recycling Washing Machine-fangsheng

Plastic Film Washing Line Video:

Learn more about YouTube’s plastic film washing line

Complete Plastic Film Washing Line:

Plastic Film Recycling Washing Machine-fangsheng

Plastic Film Washing Line Technical Parameter:

Name Motor power (kw) Dimension (mm) Water consumption (T/H) Stainless steel standard (mm) Electric standard
Belt conveyor 2.2 4500*690 According to customers standard
Wet crusher 75 2-4
Friction washer 2.2*2 3000*300 1-2 3-5
Floating washer 2.2*2+1.5 4500*1300 2-4 3-5
Screw conveyor 2.2 2500*250 1-2 3-5
High-speed friction washer 30 2-4 3-5
Screw converor 2.2 2800*300 1-2 3-5
Dewatering machine 75 5
Drying system 36
Storage hopper for transition
Drying system 36
Storage hopper 2.2*2

Plastic Film Washing Machine Detail:

Plastic Film Recycling Washing Machine-fangsheng
High-speed Friction Washer
Plastic Film Recycling Washing Machine-fangsheng
Crusher Machine
Plastic Film Recycling Washing Machine-fangsheng
Dewatering Machine
